DCL-23

Name: DCL-23 | MSA Components GmbH
SKU: c0976c0c99cb

SKU: c0976c0c99cb Categories: Capacitors, DC-Link, Film and Mica Capacitors Brand: Exxelia SAS

Exxelia’s DCL-23 is a low-ESR DC-Link film capacitor featuring low self-inductance, high thermal conductivity, and long lifetime. With polypropylene dielectric and high ripple-current capability, it supports inverters, motor drives, DC filtering, induction heating, UPS systems, and high-frequency power applications.

Do you need more details about this product?

If you need detailed information about this product, please call us or send us an email with your contact information. Our team will respond quickly.

Markus Schulte, M.Sc.

Business Developement Manager

+49 2722 6373 20 markus.schulte@msa-components.com

Send inquiry

Low Profile
Low ESR
Low Self-Inductance
High Thermal Conductivity
Long Lifetime
Integrated Mounting Flanges
IRMS: 110 AMPS
Inductance: < 13 nH

Capacitance: 40nF ~ 265µF
Voltage Rated DC: 700V ~ 1800V
Operating Temp: -55°C ~ 105°C
Tolerance: ±5%, ±10%
Dielectric: Polypropelene (PP)
RoHS: ROHS

Typical applications:

DC Filtering; Motor Drives
Inverters (Wind, Solar, Electric Vehicle)
Induction Heaters
High Frequency and High Ripple Current Applications like High Frequency PWM Inverters, High KVA On-Line UPS, Telecom SMPS, Solar Inverters, Wind-Mill Power Suppliers

Datasheet

DCL-23 Datasheet
