FP-11R-500

Name: FP-11R-500 | MSA Components GmbH
SKU: 3c949625bcd0

SKU: 3c949625bcd0 Categories: Capacitors, Film and Mica Capacitors, Power Capacitors Brand: Exxelia SAS

The Exxelia FP-11R-500 is a water-cooled, self-healing polypropylene film capacitor with low stray inductance. It supports up to 900 KHz, 1000 IRMS, and 500 KVAR, making it suitable for induction heating, electric vehicles, medical imaging, wireless EV charging, and resonant circuits.

Do you need more details about this product?

If you need detailed information about this product, please call us or send us an email with your contact information. Our team will respond quickly.

Markus Schulte, M.Sc.

Business Developement Manager

+49 2722 6373 20 markus.schulte@msa-components.com

Send inquiry

Water cooled
Polypropylene dielectric
Self-healing
Low Stray Inductance
Operating frequency up to 900 KHz
Maximum operating core temperature 85°C
Max Current: 1000 IRMS
Max Power: 500 KVAR
Frequency Range: 40 – 896 KHz
ESL: Low Stray Inductance
Size: 30.5 mm × 80 mm × 120 mm

Capacitance 200nF ~ 10µF
Voltage Rated AC 400Vac ~ 700Vac
Operating Temp 85°C
Tolerance ±10%
Dielectric Polypropylene (PP)
RoHS ROHS

Typical applications:

Induction Heating
Electric Cars
Medical Imaging
EV Wireless Chargers
Resonant Circuits

Datasheet

FP-11R-500 Datasheet
