FP-2-400

Name: FP-2-400 | MSA Components GmbH
SKU: 7089c22cb931

SKU: 7089c22cb931 Categories: Capacitors, Film and Mica Capacitors, Power Capacitors Brand: Exxelia SAS

The Exxelia FP-2-400 is a conduction-cooled power film capacitor featuring a self-healing polypropylene dielectric. It supports 150nF–2µF capacitance, 500–1000Vac ratings, frequencies up to 700kHz, ±10% tolerance, and operation at 85°C.

Do you need more details about this product?

If you need detailed information about this product, please call us or send us an email with your contact information. Our team will respond quickly.

Markus Schulte, M.Sc.

Business Developement Manager

+49 2722 6373 20 markus.schulte@msa-components.com

Send inquiry

Conduction cooled
Polypropylene dielectric
Self-healing
Operating frequency up to 700 kHz
Maximum operating core temperature: 85°C
Max Current: 800 IRMS
Max Power: 400 kVAR
Frequency Range: 110–538 kHz
ESL: < 5 nH
Size: 30.2 mm × 55 mm × 73 mm

Capacitance: 150nF ~ 2µF
Voltage Rated AC: 500Vac ~ 1000Vac
Operating Temp: 85°C
Tolerance: ±10%
Dielectric: Polypropylene (PP)
RoHS: ROHS

Typical applications:

Induction Heating
Electric Cars
Medical Imaging
EV Wireless Chargers
Resonant Circuits

Datasheet

FP-2-400 Datasheet
