FP-5-200-SM/SP

Name: FP-5-200-SM/SP | MSA Components GmbH
SKU: bc5657ef9c25

SKU: bc5657ef9c25 Categories: Capacitors, Film and Mica Capacitors, Power Capacitors Brand: Exxelia SAS

Exxelia’s FP-5-200-SM/SP is a conduction-cooled, self-healing power film capacitor with polypropylene dielectric and ultra-low ESL below 3 nH. It offers 2.4–50nF capacitance, 450–1000Vac ratings, ±10% tolerance, 85°C operation, and frequencies up to 1000kHz.

Do you need more details about this product?

If you need detailed information about this product, please call us or send us an email with your contact information. Our team will respond quickly.

Markus Schulte, M.Sc.

Business Developement Manager

+49 2722 6373 20 markus.schulte@msa-components.com

Send inquiry

Conduction cooled
Polypropylene dielectric
Self-healing
Operating frequency up to 1000 KHz
Maximum operating core temperature: 85°C
Max Current: 500 IRMS
Max Power: 200 KVAR
Frequency Range: 65 – 994 KHz
ESL: < 3 nH
Size: 30.2 mm × 30 mm × 68 mm

Capacitance: 50nF ~ 2.4nF
Voltage Rated AC: 450Vac ~ 1000Vac
Operating Temp: 85°C
Tolerance: ±10%
Dielectric: Polypropylene (PP)

Typical applications:

Induction Heating
Electric Cars
Medical Imaging
EV Wireless Chargers
Resonant Circuits

Datasheet

FP-5-200-SM/SP Datasheet
