FP-5F-200

Name: FP-5F-200 | MSA Components GmbH
SKU: b37d7b9f9d88

SKU: b37d7b9f9d88 Categories: Capacitors, Film and Mica Capacitors, Power Capacitors Brand: Exxelia SAS

The Exxelia FP-5F-200 is a conduction-cooled, self-healing polypropylene film capacitor for high-frequency power applications. It supports operation up to 1000 kHz, 450–1000 Vac, and 85°C, with low ESL below 3 nH, making it suitable for induction heating, electric vehicles, medical imaging, and resonant circuits.

Do you need more details about this product?

If you need detailed information about this product, please call us or send us an email with your contact information. Our team will respond quickly.

Markus Schulte, M.Sc.

Business Developement Manager

+49 2722 6373 20 markus.schulte@msa-components.com

Send inquiry

Conduction cooled
Polypropylene dielectric
Self-healing
Operating frequency up to 1000 kHz
Maximum operating core temperature 85°C
Max Current: 500 IRMS
Max Power: 200 kVAR
Frequency Range: 65–994 kHz
ESL: < 3 nH
Size: 30.2 mm × 30 mm × 68 mm

Capacitance: 50nF ~ 2.4nF
Voltage Rated AC: 450Vac ~ 1000Vac
Operating Temp: 85°C
Tolerance: ±10%
Dielectric: Polypropylene (PP)
RoHS: ROHS

Typical applications:

Induction Heating
Electric Cars
Medical Imaging
EV Wireless Chargers
Resonant Circuits

Datasheet

FP-5F-200 Datasheet
