FP-60-700

Name: FP-60-700 | MSA Components GmbH
SKU: 99db8851275c

SKU: 99db8851275c Categories: Capacitors, Film and Mica Capacitors, Power Capacitors Brand: Exxelia SAS

Exxelia’s FP-60-700 is a high-power polypropylene film capacitor designed for demanding high-frequency applications. It features conduction cooling, self-healing construction, low stray inductance, and operation up to 30 kHz, with ratings reaching 700 kVAR and 1400 A RMS.

Do you need more details about this product?

If you need detailed information about this product, please call us or send us an email with your contact information. Our team will respond quickly.

Markus Schulte, M.Sc.

Business Developement Manager

+49 2722 6373 20 markus.schulte@msa-components.com

Send inquiry

Conduction cooled
Polypropylene dielectric
Self-healing
Operating frequency up to 30 KHz
Maximum operating core temperature 85°C
Max Current: 1400 IRMS
Max Power: 700 KVAR
Frequency Range: 5.2 – 29 KHz
ESL: Low stray inductance
Size: 130 mm X 71 mm X 130 mm

Capacitance: 5nF ~ 85nF
Voltage Rated AC: 500Vac ~ 1000Vac
Operating Temp: 85°C
Tolerance: ±10%
Dielectric: Polypropelene (PP)
RoHS: ROHS

Typical applications:

Induction Heating
Electric Cars
Medical Imaging
EV Wireless Chargers
Resonant Circuits

Datasheet

FP-60-700 Datasheet
