FP-9-200

Name: FP-9-200 | MSA Components GmbH
SKU: 9f6855cb2d9c

SKU: 9f6855cb2d9c Categories: Capacitors, Film and Mica Capacitors, Power Capacitors Brand: Exxelia SAS

The Exxelia FP-9-200 is a compact, conduction-cooled, self-healing polypropylene film capacitor designed for high-frequency power applications. It supports frequencies up to 650 kHz, 400–700 VAC, capacitance from 5–180 nF, and temperatures up to 85°C, making it suitable for demanding resonant circuits.

Do you need more details about this product?

If you need detailed information about this product, please call us or send us an email with your contact information. Our team will respond quickly.

Markus Schulte, M.Sc.

Business Developement Manager

+49 2722 6373 20 markus.schulte@msa-components.com

Send inquiry

Conduction cooled
Polypropylene dielectric
Self-healing
Operating frequency up to 650 kHz
Maximum operating core temperature 85°C
Max Current: 500 IRMS
Max Power: 180 kVAR
Frequency Range: 635–601 kHz
ESL: < 3 nH
Size: 30.2 mm × 50 mm × 75 mm

Capacitance: 180nF ~ 5nF
Voltage Rated AC: 400Vac ~ 700Vac
Operating Temp: 85°C
Tolerance: ±10%
Dielectric: Polypropylene (PP)
RoHS: ROHS

Typical applications:

Induction Heating
Electric Cars
Medical Imaging
EV Wireless Chargers
Resonant Circuits

Datasheet

FP-9-200 Datasheet
