FP-9-300

Name: FP-9-300 | MSA Components GmbH
SKU: a1f6e964945b

SKU: a1f6e964945b Categories: Capacitors, Film and Mica Capacitors, Power Capacitors Brand: Exxelia SAS

The Exxelia FP-9-300 is a conduction-cooled, self-healing polypropylene film capacitor designed for high-power, high-frequency applications. It supports frequencies up to 700 kHz, 400–1000 Vac, 5–100 nF capacitance, and 85°C operation, with applications including induction heating, EV wireless charging, medical imaging, and resonant circuits.

Do you need more details about this product?

If you need detailed information about this product, please call us or send us an email with your contact information. Our team will respond quickly.

Markus Schulte, M.Sc.

Business Developement Manager

+49 2722 6373 20 markus.schulte@msa-components.com

Send inquiry

Conduction cooled
Polypropylene dielectric
Self-healing
Operating frequency up to 700 kHz
Maximum operating core temperature 85°C
Max Current: 800 IRMS
Max Power: 300 kVAR
Frequency Range: 59–649 kHz
ESL: < 5 nH
Size: 30.2 mm × 51 mm × 75 mm

Capacitance: 100nF ~ 5nF
Voltage Rated AC: 400Vac ~ 1000Vac
Operating Temp: 85°C
Tolerance: ±10%
Dielectric: Polypropylene (PP)
RoHS: ROHS

Typical applications:

Induction Heating
Electric Cars
Medical Imaging
EV Wireless Chargers
Resonant Circuits

Datasheet

FP-9-300 Datasheet
