KPF

Name: KPF | MSA Components GmbH
SKU: 79aef31a7adf

SKU: 79aef31a7adf Categories: Capacitors, Film and Mica Capacitors, IGBT Snubbers Brand: Exxelia SAS

The Exxelia KPF is a self-healing polypropylene film capacitor designed for IGBT protection and high-power converter applications. It offers high DV/DT, low ESR, 100nF–3µF capacitance, and 1000–2000VDC ratings for demanding power electronics circuits.

Do you need more details about this product?

If you need detailed information about this product, please call us or send us an email with your contact information. Our team will respond quickly.

Markus Schulte, M.Sc.

Business Developement Manager

+49 2722 6373 20 markus.schulte@msa-components.com

Send inquiry

Self-healing property
High DV/DT
Low ESR
Low loss polypropylene dielectric
IGBT protection circuits
Mounting Pitch: 22.5 mm TO 48 mm
Construction: Extended Foil Electrodes with Metallised Polypropylene Dielectric Internal Series Connection

Capacitance: 100nF ~ 3µF
Voltage Rated DC: 1000V ~ 2000V
Operating Temp: -40°C ~ 85°C
Dielectric: Foil, MPP
Tolerance: ±5%, ±10%
RoHS: ROHS

Typical applications:

Snubber networks
Energy conversion and control in power electronics
Protection circuits in SMPS

Datasheet

KPF Datasheet
