TCH Series

Name: TCH Series | MSA Components GmbH
SKU: f1a61bc04b32

SKU: f1a61bc04b32 Categories: Capacitors, Ceramic Capacitors, High-Temperature Brand: Exxelia SAS

Exxelia’s TCH Series ceramic capacitors deliver high-temperature and high-voltage performance up to 250°C and 10kV, with 1000-hour life under working conditions. Offering 10pF–15µF capacitance, they provide reliable operation for demanding downhole, braking, and motor control applications.

Do you need more details about this product?

If you need detailed information about this product, please call us or send us an email with your contact information. Our team will respond quickly.

Markus Schulte, M.Sc.

Business Developement Manager

+49 2722 6373 20 markus.schulte@msa-components.com

Send inquiry

Up to 250°C
1000h life time under working conditions
Up to 10kV
Formerly under the reference: TCH279, TCH281, TCH282, TCH283, TCH284, TCH288, TCH5X279, TCH5X280, TCH5X282, TCH5X283, TCH5X287

Capacitance: 10pF ~ 15µF
Voltage Rated DC: 200V ~ 10kV
Operating Temp: -55°C ~ 250°C
Tolerance: ±1%, ±2%, ±5%, ±10%, ±20%
Mounting: Radial
RoHS: ROHS, Non ROHS
Dielectric: NPO, X7R

Typical applications

Downhole tools
Breaking Systems
Motor control

Datasheet

TCH Series Datasheet
